4. Adjust sprayer for canopy density

pome-fruit trees
pre-blossom	post-blossom-full-leaf
		std
		low

stone-fruit trees
pre-blossom	post-blossom-full-leaf
		std
		low

• This adjustment takes into account the effects of: growth-stage and branch-number between tree rows and tree row-spacing.
• For products with a label dose intended for pre-blossom uses (ex. scab fungicides), adjustments for growth-stage are ignored.
• For all other products (i.e. those with a label dose rate intended for uses across the full growing season) the sprayer may be adjusted for growth-stage, branch-number and row-spacing.
• Growth stage settings are: post-blossom-full-leaf, post-blossom-early and pre-blossom.
• Branch-number settings are: high, standard (std) and low. Note the setting for high density canopies was adjusted (6 March 2012) to give a better account of dose adjustment for wide single-row or multi-row bed plantantions.
